| Hardware Features |
|---|
| Standards |
2.4GHz: IEEE802.11n, IEEE802.11g, IEEE 802.11b;
5.0GHz: IEEE 802.11ac, IEEE 802.11n, IEEE 802.11a;
IEEE802.3, IEEE802.3u,IEEE802.3ab |
| Interface |
1 x 10/100/1000M WAN port;
3 x 10/100/1000M LAN ports;
1 x 10/100/1000M IPTV port (function as a LAN port with IPTV disabled);
2 x USB 2.0 ports. |
| Antenna |
3 x 5dBi external, detachable, omni-directional antennas |
| Button |
1 x WPS/Reset button |
| Power |
Input: 100 ~ 240VAC, 50 / 60Hz 0.3A
Output: 12VDC, 2.5A |
| Dimensions (L x W x H) |
8.6 x 6.2 x 1.3 inches (218.6 x 156.5 x 33.8mm) |
| LED |
1 x Power, 1 x SYS, 1 x USB, 1 x WAN, 3 x LAN, 1 x IPTV, 1 x 5G, 1 x 2.4G, 1 x WPS |
| Wireless Features |
|---|
| Wireless Speed |
2.4G: 450Mbps
5G: 1300Mbps |
| Frequency |
Works over 2.4G and 5G concurrently |
| Basic Features |
Wireless: Enable/Disable;
SSID Broadcast: Enable/Disable
Band: 2.4GHz, 5GHz
Channel 2.4GHz: 1 - 13
Channel 5GHz: 149, 153, 157, 161, 165
Network Mode 2.4GHz: 11b/g/n mixed (default mode), 11b/g mixed, 11b, 11g
Network Mode 5GHz: 11a/n mixed (default mode), 11a
Connection List |
| Security |
Wireless MAC Address Filter (Wireless Access Control)
WEP, WPA-PSK / WPA2-PSK, WPA / WPA2
Wireless Security: Enable/Disable
WPS Fast Encryption |
| Software Features |
|---|
| Internet Connection Type |
PPPoE
Dynamic IP
Static IP |
| Operating Mode |
Wireless Router Mode
Wireless AP Mode
WDS Mode |
| DHCP Server |
DHCP Server
DHCP Client List
DHCP Reservation |
| Virtual Server |
Port Forwarding
DMZ Host
UPnP |
| Security |
Client Filter
MAC Filter
Website Filter
Remote Web Management |
| DDNS |
Yes |
| VPN Pass-through |
Yes |
| Other |
Bandwidth Control
USB Sharable: storage & printing
IPTV capable
Guest Network
MAC Clone
DDNS
Traffic Statistics
Backup & Restore configurations
Firmware upgradeable via browser |
| Others |
|---|
| Package Contents |
Wireless AC1750 Dual Band Gigabit Router (W1800R)
Power Adapter
Ethernet Cable
3 x 5dBi omni-directional antennas
Quick Install Guide
Resource CD |
| Temperature |
Operating Temperature: 32 - 104°F (0 - 40°C)
Storage Temperature: (-40g - 70°C) |
| Humidity |
Operating Humidity: 10% - 90% Relative Humidity non-condensing;
Storage Humidity: 5% - 90% Relative Humidity non-condensing. |
| Factory Defaul Settings |
IP Address: 192.168.0.1
Login User name/Password: Admin/Admin |
| Related Products |
W900U Wireless AC900 Dual-band USB Adapter
N80 Wireless N900 Concurrent Dual-band Gigabit Router
W568R Wireless N900 Concurrent Dual-band Gigabit Router |
| Certificates |
CE, FCC, RoHS |
